HSM HL-7009 Horizontal Baling Press

HSM HL-7009 Horizontal Baling Press

Regular price $89,555.99 USD
Regular price Sale price $89,555.99 USD
Sale Sold out

HSM HL-7009 Horizontal Baling Press

Compact and Powerful Waste Disposal Solution

The HSM HL-7009 horizontal baling press is a compact and powerful solution for large disposal tasks in retail and small to medium central storages. With bale dimensions of 1100 x 1100 mm and a bale length of 1200 mm, the HL-7009 produces bales weighing up to 600 kg, ensuring optimal HGV capacity and reduced handling expenses. Its integrated hydraulic lifting/tilting device makes it easy to compact recycling materials with minimal manpower.

Key Features of the HSM HL-7009 Horizontal Baling Press:

  • Versatile Compression: Suitable for both cardboard and film
  • Hydraulic Lifting/Tilting Device: Allows for fast and convenient loading
  • Automatic Start: Available as a variant with automatic start
  • Compact Design: Low space requirement thanks to a sturdy and compact design
  • Quick-Link Wire Strapping: Manual bale strapping with Quick-link wire
  • Pallet Locking Mechanism: Ensures safe bale removal
  • Intuitive Display: Multilingual operational guidance via graphic description
  • High HGV Load: High specific pressing power provides optimal compaction and HGV load
  • Hydraulic Sliding Door: Ensures optimal operating convenience and safety for bale removal

Technical Specifications for the HSM HL-7009 Horizontal Baling Press:

  • Order Number: 6336123
  • EAN: 4026631065870
  • Pressing Power: 71 tons
  • Specific Pressing Power: 84.1 psi
  • Driving Power: 14.35 HP
  • Voltage / Frequency: 208 V / 60 Hz
  • Cycle Time (Idle): 47 seconds
  • Volume Throughput (Idle, Theoretical): 3005 cu ft/h
  • Loading Aperture (W x L): 40.16" x 35.43"
  • Bale Dimensions (W x H x L): 43.31" x 43.31" x 47.24"
  • Bale Weight: 1323 lbs
  • Method of Loading: Lifting/tilting system, wire mesh cart
  • Machine Dimensions (L x W x H): 234.33" x 81.34" x 98.43"
  • Weight: 16305.37 lbs
  • Consumables Type: Wire
  • Press Material: Plastic Film, Mixed Paper, Cardboard

Upgrade your waste disposal process with the highly efficient and compact HSM HL-7009 horizontal baling press, designed to tackle large volumes of waste with ease.
